F03 - Front fork COMPETIZIONE - FC50MY07_MY08_MY09
Microfichas / FANTIC / Peças de Montagem / FC50MY07_MY08_MY09
Alternar rapidamente entre desenhos deste veículo (13):
F01 - Quadro e Chassis - FC50MY07_MY08_MY09
F02 - Swingarm - FC50MY07_MY08_MY09
F03 - Front fork COMPETIZIONE - FC50MY07_MY08_MY09
F04 - Front Fork CASA/MOTARD - FC50MY07_MY08_MY09
F05 - Roda Dianteira - FC50MY07_MY08_MY09
F06 - Roda Traseira - FC50MY07_MY08_MY09
F08 - Depósito de Combustível e Banco - FC50MY07_MY08_MY09
F09 - Guiador e Comandos - FC50MY07_MY08_MY09
F12 - Dell'Orto VHST 26 BS - FC50MY07_MY08_MY09
F13 - Dell'Orto PHBN 16 NS - FC50MY07_MY08_MY09
F14 - Adhésifs 2007 - FC50MY07_MY08_MY09
F14 - Adhésifs 2008 - FC50MY07_MY08_MY09
F14 - Adhésifs 2009 - FC50MY07_MY08_MY09
Peças do Desenho (67 itens)
| Nº | Ref. OEM | Foto | Descrição da Peça | Qtd | Disponibilidade | Preço | Comprar |
|---|---|---|---|---|---|---|---|
| 1 | 01968005 |
|
[01968005] CAP FORK F/A - FANTIC Catálogo | 1 | Sob Consulta | 65.00 € |
|
| 2 | 01969005 |
|
[01969005] CAP FORK F/R - FANTIC Catálogo | 1 | Sob Consulta | 65.00 € |
|
| 3 | 00007005 |
|
[00007005] O RING 144 - FANTIC | 2 | Sob Consulta | 0.20 € |
|
| 4 | 01934005 |
|
[01934005] NUT 20 - FANTIC Catálogo | 1 | Sob Consulta | 28.60 € |
|
| 5 | 01935005 |
|
[01935005] WASHER 40,6X24,2X2,5 CAN. - FANTIC Catálogo | 1 | Sob Consulta | 2.20 € |
|
| 6 | 01348005 |
|
[01348005] CROWN BLACK - FANTIC Catálogo | 1 | Sob Consulta | 9999999.00 € |
|
| 7 | 01936005 |
|
[01936005] SCREW-FLANGED 8X40 - FANTIC Catálogo | 8 | Sob Consulta | 4.00 € |
|
| 8 | 01349005 |
|
[01349005] PLATE FORK 125 LOW.BLACK - FANTIC Catálogo | 1 | Sob Consulta | 331.60 € |
|
| 9 | 01937005 |
|
[01937005] RING NUT 25X1 E50 - FANTIC Catálogo | 1 | Sob Consulta | 12.20 € |
|
| 10 | 01938005 |
|
[01938005] SCREW-HEXAGONAL CHEESE HEAD 8X30 - FANTIC Catálogo | 4 | Sob Consulta | 0.80 € |
|
| 13 | 01940005 |
|
[01940005] PIPE ASS.Y 40 GOLD - FANTIC Catálogo | 2 | Sob Consulta | 308.80 € |
|
| 14 | 01941005 |
|
[01941005] BUSHING-LOWER ROD GUARD - FANTIC Catálogo | 4 | Sob Consulta | 25.20 € |
|
| 15 | 01942005 |
|
[01942005] WASHER-SPACE - FANTIC Catálogo | 2 | Sob Consulta | 2.80 € |
|
| 16 | 01240005 |
|
[01240005] OIL SEAL 40X52X9.5/10.5 - FANTIC Catálogo | 2 | Sob Consulta | 9999999.00 € |
|
| 17 | 01241005 |
|
[01241005] RING-STOP 40 - FANTIC Catálogo | 2 | Sob Consulta | 1.40 € |
|
| 18 | 01242005 |
|
[01242005] COVER-DUST+SPRING - FANTIC Catálogo | 2 | Sob Consulta | 9999999.00 € |
|
| 19 | 01943005 |
|
[01943005] PIPE-TIMING - FANTIC Catálogo | 2 | Sob Consulta | 6.00 € |
|
| 20 | 01971005 |
|
[01971005] NUT 12 - FANTIC Catálogo | 2 | Sob Consulta | 1.40 € |
|
| 21 | 01972005 |
|
[01972005] PIPE-SPRING GUIDE - FANTIC Catálogo | 2 | Sob Consulta | 23.20 € |
|
| 22 | 01973005 |
|
[01973005] RING-STOP REG. - FANTIC Catálogo | 2 | Sob Consulta | 0.40 € |
|
| 23 | 01974005 |
|
[01974005] ROD ASS.Y-D5 D40 2006 ADJUSTABLE - FANTIC Catálogo | 2 | Sob Consulta | 65.00 € |
|
| 24 | 01975005 |
|
[01975005] CASE ASS.Y 40 F/R RIC.ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 81.40 € |
|
| 25 | 01976005 |
|
[01976005] BLADE 22X8.1X0.3 - FANTIC Catálogo | 2 | Sob Consulta | 1.00 € |
|
| 26 | 01944005 |
|
[01944005] PISTON RING FORK USD40 - FANTIC Catálogo | 1 | Sob Consulta | 7.60 € |
|
| 27 | 01945005 |
|
[01945005] PISTON DI.26 HOLE DI.1,5 - FANTIC Catálogo | 1 | Sob Consulta | 17.00 € |
|
| 28 | 01946005 |
|
[01946005] BLADE 23X8.1X0.15 - FANTIC Catálogo | 5 | Sob Consulta | 1.60 € |
|
| 30 | 01947005 |
|
[01947005] NUT 6 - FANTIC Catálogo | 1 | Sob Consulta | 4.40 € |
|
| 31 | 01977005 |
|
[01977005] VALVE ASS.Y 40 USD+REEDS ADJUSTABLE - FANTIC Catálogo | 2 | Sob Consulta | 39.00 € |
|
| 32 | 01978005 |
|
[01978005] CASE ASS.Y 40 F/A RIC.ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 91.00 € |
|
| 33 | 01948005 |
|
[01948005] CUP-PISTON - FANTIC Catálogo | 1 | Sob Consulta | 6.20 € |
|
| 34 | 01949005 |
|
[01949005] BLADE 19X8.1X0.2 - FANTIC Catálogo | 1 | Sob Consulta | 0.80 € |
|
| 34 | 01950005 |
|
[01950005] BLADE 17X8.1X0.2 - FANTIC Catálogo | 1 | Sob Consulta | 0.80 € |
|
| 34 | 01951005 |
|
[01951005] BLADE 21X8.1X0.2 - FANTIC Catálogo | 1 | Sob Consulta | 1.20 € |
|
| 34 | 01952005 |
|
[01952005] BLADE 11X8.1X0.1 - FANTIC Catálogo | 1 | Sob Consulta | 1.40 € |
|
| 34 | 01953005 |
|
[01953005] BLADE 23X8.1X0.15 - FANTIC Catálogo | 2 | Sob Consulta | 1.60 € |
|
| 35 | 01954005 |
|
[01954005] PISTON DI.26 VAPOR - FANTIC Catálogo | 1 | Sob Consulta | 12.20 € |
|
| 36 | 01955005 |
|
[01955005] NUT 6 - FANTIC Catálogo | 1 | Sob Consulta | 10.20 € |
|
| 39 | 01979005 |
|
[01979005] ROD ASS.Y-CPL.D40 F/R ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 331.60 € |
|
| 43 | 01956005 |
|
[01956005] SCREW-HEXAGONAL CHEESE HEAD 6X25 - FANTIC Catálogo | 2 | Sob Consulta | 0.40 € |
|
| 44 | 01425005 |
|
[01425005] PIPE ASS.Y+FOOT RIGHT ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 399.80 € |
|
| 45 | 01426005 |
|
[01426005] PIPE ASS.Y+FOOT LEFT ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 412.80 € |
|
| 46 | 01957005 |
|
[01957005] SPRING 34,4 - FANTIC Catálogo | 2 | Sob Consulta | 40.40 € |
|
| 47 | 01980005 |
|
[01980005] PIPE-PRELOADING 35X2,5X65 - FANTIC Catálogo | 2 | Sob Consulta | 4.00 € |
|
| 48 | 01958005 |
|
[01958005] WASHER COPPER 16X10 - FANTIC Catálogo | 2 | Sob Consulta | 0.80 € |
|
| 49 | 01981005 |
|
[01981005] SCREW-HEXAGONAL CHEESE HEAD 10X30 - FANTIC Catálogo | 2 | Sob Consulta | 0.80 € |
|
| 52 | 01959005 |
|
[01959005] SPRING 8 - FANTIC Catálogo | 2 | Sob Consulta | 0.60 € |
|
| 53 | 01982005 |
|
[01982005] RING-STOP 27X1,2 - FANTIC Catálogo | 2 | Sob Consulta | 0.60 € |
|
| 54 | 01983005 |
|
[01983005] ROD ASS.Y-CPL.D40 F/A ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 334.80 € |
|
| 55 | 01984005 |
|
[01984005] ROD ASS.Y+STUD BOLT F/R RIC.ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 104.00 € |
|
| 56 | 01985005 |
|
[01985005] ROD ASS.Y+STUD BOLT F/A RIC.ADJUSTABLE - FANTIC Catálogo | 1 | Sob Consulta | 104.00 € |
|
| 61 | 01846005 |
|
[01846005] U BOLT BLACK - FANTIC Catálogo | 2 | Sob Consulta | 8.60 € |
|
| 62 | 01960005 |
|
[01960005] SCREW-HEXAGONAL HEAD 10X60 - FANTIC Catálogo | 2 | Sob Consulta | 1.00 € |
|
| 63 | 01961005 |
|
[01961005] LOWER HANDLEBAR CLAMP - FANTIC Catálogo | 2 | Sob Consulta | 30.60 € |
|
| 64 | 01838005 |
|
[01838005] RUBBER U BOLT - FANTIC Catálogo | 4 | Sob Consulta | 1.80 € |
|
| 65 | 01839005 |
|
[01839005] PIPE-HANDLEBAR - FANTIC Catálogo | 2 | Sob Consulta | 9999999.00 € |
|
| 66 | 01962005 |
|
[01962005] CUP-STOP HANDLEBAR - FANTIC Catálogo | 2 | Sob Consulta | 2.40 € |
|
| 67 | 01963005 |
|
[01963005] NUT-LOCK 10 - FANTIC Catálogo | 2 | Sob Consulta | 1.80 € |
|
| 68 | 00877005 |
|
[00877005] GUARD-ROD BLACK FORK 40 - FANTIC Catálogo | 1 | Sob Consulta | 22.60 € |
|
| 68 | 01866005 |
|
[01866005] GUARD-ROD WHITE FORK 40 - FANTIC Catálogo | 1 | Sob Consulta | 9999999.00 € |
|
| 69 | 00082005 |
|
[00082005] SWINGARM PLATE WATER GUARD DISC - FANTIC | 2 | Em Stock (2 un) | 6.80 € |
|
| 70 | 00007005 |
|
[00007005] O RING 144 - FANTIC | 2 | Sob Consulta | 0.20 € |
|
| 71 | 00831020 |
|
[00831020] FORK ASS.Y M.ADJUSTABLE GOLD - FANTIC Catálogo | 1 | Sob Consulta | 1469.00 € |
|
| 72 | 00301005 |
|
[00301005] CABLE GUIDE - FANTIC Catálogo | 1 | Sob Consulta | 3.20 € |
|
| A | 01964005 |
|
[01964005] BLADES 0,30-KIT - FANTIC Catálogo | 1 | Sob Consulta | 195.00 € |
|
| A | 01965005 |
|
[01965005] BLADES 0,10-KIT - FANTIC Catálogo | 1 | Sob Consulta | 260.00 € |
|
| A | 01966005 |
|
[01966005] BLADES 0,15-KIT - FANTIC Catálogo | 1 | Sob Consulta | 260.00 € |
|
| A | 01967005 |
|
[01967005] BLADES 0,20-KIT - FANTIC Catálogo | 1 | Sob Consulta | 260.00 € |
|
